스틸맥스(주)가 쓰는 Steel story — CSA 300W
CSA 300W — Canadian Standards Carbon Steel Plate



CSA (Canadian Standards Association) 캐나다 표준 국가 규격의 약칭입니다.
그 중에 나타나는 CSA 300W강종의 화학 성분은

C :  0.22% 이하
Si : 0.4% 이하
Mn : 0.50~1.50% 이하
P : 0.04% 이하
S : 0.05% 이하
Ti : 0.10% 이하의 강재로
인장강도는 410 ~ 590 MPa 급입니다.
제조 Process는 AR 또는 Normalizing 열처리 공정으로 생산되는 강종입니다.

※ Normalizing (불림 :燒準)
Heat treatment consisting of austenitizing followed by air cooling.
The purposes of this operation are to eliminate the influence of pre-working,
to render the crystal grains finder and to improve their mechanical properties.

오스테나이트화 후 공기 중에서 냉각하는 열처리로
노말라이징 열처리의 목적은 강재 생산 앞공정에서 받은 응력 (Stress)를 풀어주고
결정립을 미세화, 표준화 시켜, 기계적 성질을 향상 시키는 열처리를 말합니다.

※ 열처리 ( Heat Treatment : 熱處理)
철강재의 전체 또는 일부에  열 싸이클을 적용하여 그 성질 또는 조직을 변화 시키는
일련의 작업으로, 철강재의 화학 조성은 이러한 작업 과정으로 변할 수 있습니다.

Series of operations in the course of which a solid ferrous product is totally or
or partially exposed to thermal cycles to bring about a change in its
properties and/or structure.
The chemical composition of the ferrous product may possibly be
modified during these operations.



DSC02326

CSA 300W, Canadian Standards Plate, CSA(Canadian Standards Association) 300W 규격으로 생산된 후판의 측면 Marking



스틸맥스는 연구소 수준의
깊이 있는 철강에 대한 이해를 바탕으로,

Carbon Steel, Special Steel, Stainless, Functional steel,
Ni-Alloy, Copper Alloy, Aluminium Alloy, Forging .

Plate, Sections, H-BEAM, Angle, Channel,
Flat, Round Bar, Rail, Pipe & Tube, SMLS,

ASTM, ASME, AISI, ANSI, API, SAE, AS, CSA
EN , KS, JIS, DNV, ABS, GL, LR, KR, NK. RINA, RS, CCA, IACS의

국가규격, 국제단체 규격, 국제협회 규격부터
Mill Maker Standards까지 공급하고 있습니다.
