SAE J2614, 500 MPa Tensile Strength Tube
STEELMAX Steel Story



SAE J2614 규정은 Hydraulic Tube 이고, 인장강도 500 MPa minimum의
저합금 고강도 (HSLA : High Strength Low Alloy) 강재입니다.

미량 합금 원소인 니오븀, 티타늄 바나듐 합금과 냉간 가공으로 높은 강도입니다.
Normalizing 또는 Annealed 열처리 한, 전기 저항 용접 (ERW) 튜브입니다.

열처리성 높은 미량 합금 원소의 영향으로 탄소강재인 SAE J525,
SAE J2467 보다, 높은 기계적 성질로, 고압 용도로 사용되는 튜브입니다.

SAE J2614 재질의 인장강도 500 MPa minimum 을 JIS SM490A
인장강도 490 MPa minimum 과 비교하면, 재질 강도가 비교됩니다.

※ Annealing (풀림 열처리)
Heat treatment consisting of heating and soaking at a suitable
temperature followed by cooling under conditions such that,
after return to ambient temperature, the metal will be in
a structural state closer to that of equilibrium.
Annealing is a heat treatment process to transform the steel
structure in to a more homogeneous, soft or more suitable state
Note : Since this definition is very general, it is advisable to use an
expression specifying the aim of the treatment (see bright annealing,
full annealing, soft annealing, inter-critical annealing, isothermal
annealing and subcritical annealing)

금속 재료를 적당한 온도로 가열하고, 그 온도에서 유지하는 균질화 처리를
한 뒤, 냉각함으로써 냉각 후 상온에서의 조직이 평형 상태에
가깝도록 하는 열처리를 말합니다.
이 용어는 아주 광범위하게 사용되므로 처리하는 목적을 덧붙여
사용하는 것이 바람직하다. 예를 들어 광휘 어닐링, 완전 어닐링,
연화 어닐링, 중간 어닐링, 등온 어닐링, 변태점 이하 어닐링.

※ Normalizing (불림 : 燒準)
Heat treatment consisting of austenitizing followed by air cooling.
The purposes of this operation are to eliminate the influence of pre-working,
to render the crystal grains finder and to improve their mechanical properties.

오스테나이트화 후 공기 중에서 냉각하는 열처리로
노말라이징 열처리의 목적은 강재 생산 앞 공정에서 받은 응력 (Stress)를 풀어주고
결정립을 미세화, 표준화 시켜, 기계적 성질을 향상시키는 열처리를 말합니다.



SAE J2614
Chemical composition (%) Carbon (C) 0.18 max
Manganese (Mn) 1.50 max
Sulfur (S) 0.035 max
Phosphorus (P) 0.035 max
Silicon (Si) 0.35 max
Aluminum (Al) 0.020 min
Nb, Ti, V 0.15 max
Yield strength (MPa) 345 min
Tensile strength (MPa) 500 min
Elongation (%) 30 min
Hardness Rockwell B90 max





AISI-SAE
